| CPU |
Intel Socket LGA1700 for 13th Gen Intel Core™ & 12th Gen Intel Core™, Pentium Gold and Celeron Processors
Intel Socket LGA1700 for 12th Gen Intel Core™, Pentium Gold and Celeron Processors* |
| Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** |
| * Refer to www.asus.com for CPU support list. |
| ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset |
Intel B660 Chipset |
| Memory |
4 x DIMM, Max. 128GB, DDR4 5333(OC) /5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory* |
| Dual Channel Memory Architecture |
| Supports Intel Extreme Memory Profile (XMP) |
| OptiMem II |
| *Actual memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). |
| Graphics |
1 x DisplayPort** |
| 1 x HDMI port*** |
| * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. |
| **Supports 4K@60Hz as specified in DisplayPort 1.4. |
| ***Supports 4K@60Hz as specified in HDMI 2.1. |
| Expansion Slots |
Intel 12th Gen Processors |
| 1 x PCIe 5.0 x16 slot(s) |
| Intel B660 Chipset* |
| 1 x PCIe 3.0 x16 slot (supports x4 mode) |
| 2 x PCIe 4.0 x1 slots |
| * Supports Intel Optane Memory H Series on PCH-attached PCIe slot |
| Storage |
Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports* |
| Intel 12th Gen Processors |
| M.2_1 slot (Key M), type 2242/2260/2280 |
| - Intel 12th Gen processors support PCIe 4.0 x4 mode. |
| Intel B660 Chipset** |
| M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x2 mode) |
| 4 x SATA 6Gb/s ports |
| * Intel Rapid Storage Technology supports SATA RAID 0/1/5/10. |
| ** Intel Rapid Storage Technology supports Intel Optane Memory H Series on PCH attached M.2 slots. |
| Ethernet |
1 x Intel 2.5Gb Ethernet |
| TUF LANGuard |
| Wireless & Bluetooth |
Intel Wi-Fi 6 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Supports 2.4/5GHz frequency band Bluetooth v5.2 |
| USB |
Rear USB (Total 8 ports) |
| 1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C) |
| 4 x USB 3.2 Gen 2 port(s) (4 x Type-A) |
| 1 x USB 3.2 Gen 1 port(s) (1 x Type-A) |
| 2 x USB 2.0 port(s) (2 x Type-A) |
| Front USB (Total 7 ports) |
| 1 x USB 3.2 Gen 1 connector (supports USB Type-C) |
| 1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports |
| 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports |
| Audio |
Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback |
| Audio Features |
| - Rear optical S/PDIF out port |
| - Premium audio capacitors |
| - Dedicated audio PCB layers |
| Back Panel I/O Ports |
1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C) |
| 4 x USB 3.2 Gen 2 port(s) (4 x Type-A) |
| 1 x USB 3.2 Gen 1 port(s) (1 x Type-A) |
| 2 x USB 2.0 port(s) (2 x Type-A) |
| 1 x DisplayPort |
| 1 x HDMI port |
| 1 x Wi-Fi Module |
| 1 x Intel 2.5Gb Ethernet port |
| 5 x Audio jacks |
| 1 x Optical S/PDIF out port |
| Internal I/O Connectors |
Fan and Cooling related |
| 1 x 4-pin CPU Fan header(s) |
| 1 x 4-pin CPU OPT Fan header(s) |
| 1 x 4-pin AIO Pump header(s) |
| 3 x 4-pin Chassis Fan header(s) |
| Power related |
| 1 x 24-pin Main Power connector |
| 1 x 8-pin +12V Power connector |
| 1 x 4-pin +12V Power connector |
| Storage related |
| 2 x M.2 slots (Key M) |
| 4 x SATA 6Gb/s ports |
| USB |
| 1 x USB 3.2 Gen 2 connector (support(s) USB Type-C) |
| 1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports |
| 2 x USB 2.0 header(s) support(s) additional 4 USB 2.0 ports |
| Miscellaneous |
| 3 x Addressable Gen 2 header(s) |
| 1 x AURA RGB header(s) |
| 1 x Clear CMOS header |
| 1 x COM Port header |
| 1 x Front Panel Audio header (AAFP) |
| 1 x 20-3 pin System Panel header with Chassis intrude function |
| 1 x Thunderbolt™ header |
| Special Features |
ASUS TUF PROTECTION |
| - DIGI+ VRM (- Digital power design with DrMOS) |
| - Enhanced DRAM Overcurrent Protection |
| - ESD Guards |
| - TUF LANGuard |
| - Overvoltage Protection |
| - Safeslot |
| - Stainless-Steel Back I/O |
| ASUS Q-Design |
| - M.2 Q-Latch |
| - Q-DIMM |
| - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) |
| - Q-Slot |
| ASUS Thermal Solution |
| - M.2 heatsink |
| - VRM heatsink design |
| ASUS EZ DIY |
| - CPU Socket lever protector |
| - ProCool |
| - Pre-mounted I/O shield |
| - SafeDIMM |
| AURA Sync |
| - AURA RGB header(s) |
| - Addressable Gen 2 header(s) |
| Software Features |
ASUS Exclusive Software |
| Armoury Crate |
| - AURA Creator |
| - AURA Sync |
| - Fan Xpert 2+ |
| - Two-Way AI Noise Cancelation |
| AI Suite 3 |
| - Performance And Power Saving Utility |
| TurboV EVO |
| EPU |
| DIGI+ VRM |
| TUF GAMING CPU-Z |
| DTS Audio Processing |
| MyAsus |
| Norton Anti-virus software (Free Trial version) |
| WinRAR |
| UEFI BIOS |
| ASUS EZ DIY |
| - ASUS CrashFree BIOS 3 |
| - ASUS EZ Flash 3 |
| - ASUS UEFI BIOS EZ Mode |
| BIOS |
128 Mb ROM, UEFI AMI BIOS |
| Manageability |
WOL by PME, PXE |
| Accessories |
Cables |
| 2 x SATA 6Gb/s cables |
| Miscellaneous |
| 1 x ASUS Wi-Fi moving antennas |
| 2 x M.2 Rubber Package(s) |
| 1 x M.2 SSD screw package(s) |
| 1 x TUF Gaming sticker |
| Installation Media |
| 1 x Support DVD |
| Documentation |
| 1 x TUF Certification card |
| 1 x User guide |
| Operating System |
Windows 11 64-bit, Windows 10 64-bit |
| Form Factor |
microATX |
| 24.4 cm x 24.4 cm |
