| CPU |
Intel Socket LGA1700 for 13th Gen Intel Core™ Processors & 12th Gen Intel Core™, Pentium Gold and Celeron Processors* |
| Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** |
| * Refer to www.asus.com for CPU support list. |
| ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset |
Intel H770 Chipset |
| Memory |
4 x DIMM, Max. 128GB, DDR4 5066(OC)/5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3400(OC)/3333(OC)/3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory* |
| Dual Channel Memory Architecture |
| Supports Intel Extreme Memory Profile (XMP) |
| OptiMem |
| * Supported memory types, data rate(Speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list. |
| Graphics |
1 x DisplayPort** |
| 1 x HDMI port*** |
| * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. |
| ** Supports max. 4K@60Hz as specified in DisplayPort 1.4. |
| *** Supports 4K@60Hz as specified in HDMI 2.1. |
| Expansion Slots |
Intel 13th & 12th Gen Processors* |
| 1 x PCIe 5.0 x16 slot |
| Intel H770 Chipset |
| 2 x PCIe 4.0 x16 slots (support x4 mode) |
| 2 x PCIe 3.0 x1 slots |
| * Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/). |
| Note: To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals. |
| Storage |
Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports* |
| Intel 13th & 12th Gen Processors |
| M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) |
| Intel H770 Chipset |
| M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) |
| M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes) |
| 4 x SATA 6Gb/s ports |
| * Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10. |
| Ethernet |
1 x Realtek 2.5Gb Ethernet |
| Wireless & Bluetooth |
Vertical M.2 slot only (Key E, CNVi & PCIe)* * Wi-Fi module is sold separately. |
| USB |
Rear USB (Total 8 ports) |
| 3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C) |
| 3 x USB 3.2 Gen 1 ports (3 x Type-A) |
| 2 x USB 2.0 ports (2 x Type-A) |
| Front USB (Total 7 ports) |
| 2 x USB 3.2 Gen 1 headers support 4 additional USB 3.2 Gen 1 ports |
| 2 x USB 2.0 headers support 3 additional USB 2.0 ports |
| Audio |
Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback |
| Audio Features |
| - Audio Shielding |
| - Premium audio capacitors |
| - Dedicated audio PCB layers |
| * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. |
| Back Panel I/O Ports |
3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C) |
| 3 x USB 3.2 Gen 1 ports (3 x Type-A) |
| 2 x USB 2.0 ports (2 x Type-A) |
| 1 x DisplayPort |
| 1 x HDMI port |
| 1 x Vertical M.2 slot (Key E) |
| 1 x Realtek 2.5Gb Ethernet port |
| 3 x Audio jacks |
| Internal I/O Connectors |
Fan and Cooling related |
| 1 x 4-pin CPU Fan header |
| 1 x 4-pin AIO Pump header |
| 3 x 4-pin Chassis Fan headers |
| Power related |
| 1 x 24-pin Main Power connector |
| 1 x 8-pin +12V Power connector |
| Storage related |
| 3 x M.2 slots (Key M) |
| 4 x SATA 6Gb/s ports |
| USB |
| 2 x USB 3.2 Gen 1 headers support 4 additional USB 3.2 Gen 1 ports |
| 2 x USB 2.0 headers support 3 additional USB 2.0 ports |
| Miscellaneous |
| 3 x Addressable Gen 2 headers |
| 2 x Aura RGB headers |
| 1 x Clear CMOS header |
| 1 x COM Port header |
| 1 x Front Panel Audio header (AAFP) |
| 1 x S/PDIF Out header |
| 1 x SPI TPM header (14-1pin) |
| 1 x 20-3 pin System Panel header with Chassis intrude function |
| 1 x Thunderbolt™ (USB4) header |
| Special Features |
ASUS 5X PROTECTION III |
| - DIGI+ VRM |
| - LANGuard |
| - Overvoltage Protection |
| - SafeSlot Core+ |
| - Stainless-Steel Back I/O |
| ASUS Q-Design |
| - Q-DIMM |
| - Q-LED Core |
| - Q-Slot |
| ASUS Thermal Solution |
| - M.2 heatsink |
| - VRM heatsink design |
| ASUS EZ DIY |
| - ProCool |
| Aura Sync |
| - Aura RGB headers |
| - Addressable Gen 2 headers |
| Software Features |
ASUS Exclusive Software |
| Armoury Crate |
| - Aura Creator |
| - Aura Sync |
| - Fan Xpert 2+ |
| - Power Saving |
| AI Suite 3 |
| - DIGI+ VRM |
| - PC Cleaner |
| ASUS CPU-Z |
| Norton 360 Deluxe (60 Days Free Trial) |
| WinRAR |
| UEFI BIOS |
| ASUS EZ DIY |
| - ASUS CrashFree BIOS 3 |
| - ASUS EZ Flash 3 |
| - ASUS UEFI BIOS EZ Mode |
| BIOS |
192 (128+64) Mb Flash ROM, UEFI AMI BIOS |
| Manageability |
WOL by PME, PXE |
| Accessories |
Cables |
| 2 x SATA 6Gb/s cables |
| Miscellaneous |
| 1 x I/O Shield |
| 1 x M.2 Rubber Package |
| 2 x Screw Packages for M.2 SSD |
| Documentation |
| 1 x User guide |
| Operating System |
Windows 11, Windows 10 64-bit |
| Form Factor |
ATX Form Factor |
| 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
